TSH高溫型冷卻塔特性

１．外殼由F.R.P製成，不老化、不生鏽、耐酸鹼、免保養。瓶形塔體輕量型小，不佔場地，任何方向均可安裝。
２．TSG-350RT以下採用F.R.P.連體成型設計，免除鐵製腳架之使用，充分發揮F.R.P.材質之特點，為全國最大
        格規F.R.P.連體成型冷卻水塔。
３．散熱材選用特殊防腐處理之木材，可耐高溫、不易阻塞，對於惡劣水質及高溫循環水之冷卻，效果最佳。
４．自動散水器採低水壓設計，軸心選用不鏽鋼材質，附有軸承輔助，磨損率最低。
５．TSH-175RT以上採用冷卻水塔專用之齒輪減速機，經久耐用，保養簡單，效率最高。
６．所有鐵件均用熱浸鍍鋅處理，免保養，不虞腐蝕。

Special Feathers
1.Casing and basin are made of durable rust proof Fiberglass Reinforced Plastic (F.R.P.) Hot dip galvanized    bolts and steel make for a completely rust free tower and provide long life. Light weight design makes    installation easy.
2.The filler is assembled with preservative treated wood, giving the finest operation under poor water conditions    and high temperature.
3.Alloy sprinkler is made with stainless steel shaft and bearings. Low water pressure automatically rotates    head for even water distribution and long life.
4.High efficiency design minimizes power consumption and operation costs.
5.For TSH-175RT and larger models, we have a specially designed gear reducer for maximum efficiency, long    life and minimum maintenance.


規格
Tower Model TSH- 		重量
Weight (Kg) 		基礎架尺寸
Concrete Foundation Layout (m/m) 		基礎螺絲
Anchor Bolt (m/m) 		泵揚程Pump Head (m)
自重
DRY 		運轉重量
Operating 		D1 D2 W A B C h Size Length  Q'ty
100 1290 2940 2100 　 1050 　 300 300 300 12 120 5 3.5
125 1520 3460 2420 　 1210 　 300 300 300 12 120 5 3.5
150 1810 3945 2760 　 1056 　 300 300 300 12 120 7 3.7
175 2040 4560 2760 　 1056 　 300 300 300 12 120 7 3.7
200 2560 5500 3080 　 1179 　 300 300 300 16 200 7 4.0
250 3160 6320 3080 　 1179 　 300 300 300 16 200 7 4.5
300 3600 6850 3970 　 1519 　 300 600 300 16 200 7 4.5
350 4180 7900 3970 　 1519 　 300 600 300 16 200 7 4.5
400 5535 10255 5100 　 2550 　 500 1000 300 16 200 12 5.5
500 6245 12050 5100 　 2550 　 500 1000 300 16 200 12 5.5
600 7780 14660 6300 3750 2411 300 500 1000 300 16 200 16 6.0
700 8740 16310 6300 3750 2411 300 500 1000 300 16 200 16 6.0
800 10950 17550 7100 4460 2717 300 500 1200 300 20 200 16 6.5
1000 12320 19670 7100 4460 2717 300 500 1200 300 20 200 16 6.5

1. IN: Water-Inlet  2. OUT: Water-Outlet  3. O: Overflow  4. Dr: Drain  5. Ba: Auto Back-up  6. Q: Back-up

Nominal Cooling Capacity is based on Water-Inlet 48ºC(118ºF), Water-Outlet 33ºC(91ºF); Ambient W. Bulb 27ºC(80ºF)

*We reserve the rights to revise the specification without notice.
